this suppressor was created to be used on the RTI arm Prophet or Priest 2. it fits perfectly above the barrel up to very close to the tank. it was printed in both PLA and Nylon carbon fiber. in pla it is more noisy. it was designed to be used with the 5.5 caliber with a power of 7.5 joules, but I think I can work well at any power. to print it it is better to make the muzzle adhere to the heated bed of the printer. have fun! (it was added for a fee only because I had to do about ten tests before having a good result!)

  soon I will also upload the more classic version of this object, always with a joint on the barrel, one with a thread is being studied.

printing instructions

printed with 100% fill, 0.6 mm nozzle and 0.3 mm layer height. printing time 9 hours approximately. check the final diameter before printing and, if necessary, insert a scale factor of 1.01 - 1.02 (it depends on the type of finish that is used) it must fit firmly only in the last section of the bushing, it can help to warm the mouthpiece to have a perfect locking

for any question please contact me!

v2 improved front thickness and increased suppressive power with greater number of internal cones (be careful if you use high pressures)

Print Settings

Printer brand:

Anycubic

Printer:

Delta

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.3 Z   and  0.6 nozzle

Filament brand:

Sain Smart

Filament material:

Nylon Carbon fibre or PLA
