NebHolder
Free
SummaryNebHolder: Many very young children on ventilator support use in-line nebulizer support. These nebulizers are not held to the face, instead are inlined through the ventilator tubing port. The Nebulizers unfortunately come with support for hand held/mask supply - which makes business sense since majority of the users are of that age group. However for infants who are scared already of all the medical equipment, a little bit of a distraction is useful. Further, trying to keep these nebulizers stable with a kicking and active child is even more hard. Hence.. the Nebulizer Holder :). This uses the Utils/Nutjob (http://www.thingiverse.com/thing:193647) nut_6x9.stl embedded into the carraige and needs a washer and an additional nut_6x9.stl jack to hold things together. TBD: I wish i had changed the smokestack to be a little wider to fit in the tip of the neb tube when changing, but it can be stuck up in the carriage way as well. I also think this design can be modified with a small motor and AA battery holder in carraige way to give periodic shake to the neb cup to help the meds move along. This print also requires support (unfortunately for the open carraige...) i used 15% for support, 20% infill. Overall, please be careful NOT to pinch the tubing when Neb is pushed in. Also Available here: (including the freeCAD files): https://github.com/nmenon/3DPrints/tree/master/Sushruta/NebHolderPrint SettingsPrinter Brand: LulzBotPrinter: MiniRafts: Doesn't MatterSupports: YesInfill: 20%Notes: I used Lines support of 15% to ensure I can cleanup inside the carraige way. NOTE: the carraigeway and the roof looks a little disconnected - that is unintentional, but helps to keep the carraigeway a little flexible. I used HIPS for the train/nebholder, ABS for wheels and support stand.

Loading comments...

Loading prints...

NebHolder

likes
0 collections
Creative Commons Attribution-ShareAlike

You can distribute, remix, adapt, and build upon the material in any medium or format, as long as attribution is given and your contributions are under the same license.

CC BY-SA Licensed under CC BY-SA
Files Included

5 downloadable files:

View 3D
RearWheel.stl
STL Model
19.8 KB
File size
View 3D
Jack.stl
STL Model
56.5 KB
File size
View 3D
FrontWheel.stl
STL Model
18.6 KB
File size
View 3D
Leg.stl
STL Model
212.5 KB
File size
View 3D
NebHolder.stl
STL Model
424.9 KB
File size
