Beautiful spiral patterns lampshade inspired by formaliz3d designs.
Perfectly suitable for a standard E27 lightbulb (110mm height x 60mm wide).
Works with most sockets.
Can be printed in both ABS and PLA (that's what we printed with). Check the images for the correct print position.
The top screw is a M9 or a M10, depending on your needs
You can print it in any filament color and spray paint it afterwards (that's what we did, anyway)
Check the attached image for dimensions. If you need a different size to fit the light socket or the bulb, just drop a message or post a comment.
The zip file has 5 stl files:
M9_screw.stl / M10_screw.stl
- .1 mm layer height
- 30% infill
- no support
- 0.586/0.637 meters of filament ~ 1.76g/1.91g
- about 1h 30 minutes @ 3000mm/s
socket_top_cover.stl
- .2 mm layer height
- 30% infill
- no support
- 1 meter of filament ~ 3.07g
- about 20 minutes @ 3000mm/s
lamp_shade_top.stl
- .3mm layer height
- no infill
- no support
- 3.131 meters of filament ~ 9.42g
- about 1h 20 minutes @ 3000mm/s
lamp_shade_bottom.stl
- .3mm layer height
- no infill
- no support
- 12 meters of filament ~ 36.21g
- about 4h 25 minutes @ 3000mm/s
Loading prints...
Spiral pattern lampshade
Creative Commons Public Domain
The creator has waived all rights to the work. You can copy, modify, distribute and perform the work, even for commercial purposes, without asking permission.
Licensed under CC0
