This is FLUDD - the Flash Liquidizer Ultra Dousing Device from Super Mario Sunshine.
Modeled in Fusion 360. The design is split into multiple pieces, intended to fit the build plate of a Lulzbot Mini (155mmx155mmx158mm). Most pieces slot together for easy assembly, and are designed to print with no supports. See the exploded view for assembly instructions.
I have printed out some of the parts from the top section to depict the functionality of the design. I intend to print out the rest of the pieces and then sand and paint them.
The design is intended to be wearable and functional to an extent (it doesn't actually shoot water, but the head and arms can rotate). The design has a slot to attach a belt to wear it, but I'm not sure how well it works.
Print Settings
- Infill - I'm using 10% infill. Use higher infill if you want stronger parts.
- Layer Height - 0.2mm for most parts. For parts that require less detail, higher layer heights can be used to save print time. Finer layers will cut time for sanding.
- Supports - Most parts can print with no supports. There are a few parts with small overhangs that could benefit from supports, like the "pump base" part, which has an overhang for the belt slot.
- Assembly - See exploded view and sectional view for assembly help.
