This is a remote control vehicle, powered by a LiPo battery and two 730 RPM gearmotors from Servocity (#638260). The wheels and structure are all printed without support, and are held together with #10 hardware (the gears attached directly to the motors are an exception, and use 8-32 screws). The wheels are driven by gears from the motors, and are constrained by the Motor-Wheel Clamps with a clearance of 1 mm for clean rotation with aligned layer lines.
Printed Parts required:
- x1 Battery Housing
- x1 Controller-Reciever Housing
- x2 Hub Mounted Gear
- x2 Wheel
- x2 Motor-Wheel Clamp
- x2 Motor-Wheel Clamp Mirror
Non-printed Parts required:
- 2x5 Sabertooth Motor Controller
- LiPo Batter (7 cell used as shown)
- RC controller/receiver (Standard for RC planes)
- x6 #10 Screws, 1.5 inch
- x8 #10 Screws, 0.75 inch
- x8 #10 Screws, 0.5 inch
- x22 #10 Nuts, any type
