Bevel gear 1:3 for Extruder
Free
Bevel gear 1:3 for Extruder - Thumbnail 1 Bevel gear 1:3 for Extruder - Thumbnail 2 Bevel gear 1:3 for Extruder - Thumbnail 3 Bevel gear 1:3 for Extruder - Thumbnail 4
SummaryRate reduction 1:3 M5 bolts make the shaft M4 the hexagonal screws Dimensions: Gear: D (out) 43 mmm, hole 4,86 mm Pinion: hole 4,8mm
