Blinkini (LCD Shutter Top)
Free
Summary This is a top I made out of LCD shutter glass for the Shenzhen Maker Faire. There is a "Safe For Work" version of the build video attached. This gallery has more details on the build process: http://imgur.com/a/pk2Xd but is NSFW-ish (but no nudity). I'll be cleaning this up in the next week or so, but this should get anyone interested in playing around with LCD shutter glass started. The download files include a BOM, Fritzing diagrams and Arduino sketches. Print Settings Printer: FlashForge Creator Pro Rafts: Yes Supports: Yes Resolution: .2mm Infill: 50-100% Notes: Printed in eSun ABS. Because it goes around your chest breathing can put quite a strain on the plastic parts- and if they crack, glass edges could be exposed. So print strong and test break the prints to make sure they are strong. Custom Section

Loading comments...

Loading prints...

Blinkini (LCD Shutter Top)

likes
26 collections
Creative Commons Attribution

You can distribute, remix, adapt, and build upon the material in any medium or format, as long as attribution is given to the creator.

CC BY Licensed under CC BY
Files Included

6 downloadable files:

View 3D
Control_pack-top.stl
STL Model
198.3 KB
File size
View 3D
LCD_Front.stl
STL Model
131.2 KB
File size
View 3D
LCD_Back.stl
STL Model
131.6 KB
File size
View 3D
Control_pack-bottom.stl
STL Model
115.8 KB
File size
View 3D
Control_pack-buckle.stl
STL Model
276.3 KB
File size
Bill_of_Materials.txt
.TXT File
Size varies
File size
Free download - login required
Downloaded: 657 times
