Printing Recommendations: (Total print time = +/- 23 hrs, +/- 265 grams of filament, Largest Dimension 190mm)

Infill: 5% - Hexagon

Filament: PLA / PETG

Layer: .2mm

Print orientation

Center Console: Rotate -65 degrees, no supports, 3 Perimeters

Dash: On Back, Rotate 100 degrees

Required Materials for Installation: 6 - 3x6mm, 6 - 3x10mm, 180mm Velcro, Paint, 1x Sewing Pin with Ball Head, Glue

There are two sets of Seat Mounts. The Body Mount and Dash Mount is designed to attach the interior to the body of the truck with velcro.

The standard seat mount is designed to attach the seats to the skids from the bottom using the two innermost running board screw holes(4x 3x16mm). The screws in the bottoms of the seats will then slip into the slots and slide backwards allowing the interior to be removed for battery access and maintenance (the Dash Mount is not used in this instance).

Download the attached Instructions PDF for installation guidance.
