Brickwall Diorama Planter
Free

I needed a planter for my desert rose (adenium obesum). So I started to design something. At this point it got all out of hands...

This is a diorama of an oldfashioned, dark and forgotten corner of an unknown street. Some might remember John Carpenter's movie "They Live" which I used for the billboards. If you do not like them, just leave the billboards away as they are optional. The street lamp really works. Inside is a golden 5mm LED wired in parallel to a 1.5F goldcap capacitor. It can be charged with a 5V smartphone powerbank. The micro USB connector is on the backside. I used a 100 Ohm resistor (serial to the LED) to protect the LED. With a 10 seconds charge the LED will stay lit for about 15 minutes.

The lamp, the posts, the billboards, the manhole cover and the glas are printed at a layer height of 0.1mm. I recommend to use 0.2mm for the rest. Drybrush everything with dark colors to give it a used and grubby look. The planter, the posts and the lamp need support.

Loading comments...

Loading prints...

Brickwall Diorama Planter

likes
1 collection
Creative Commons Attribution-NonCommercial-ShareAlike

You can distribute, remix, adapt, and build upon the material in any medium or format for noncommercial purposes only, with attribution and under the same license.

CC BY-NC-SA Licensed under CC BY-NC-SA
Files Included

9 downloadable files:

View 3D
brick-stones.stl
STL Model
8.9 MB
File size
View 3D
brick-billboard.stl
STL Model
7.7 KB
File size
View 3D
brick-glas.stl
STL Model
227.6 KB
File size
View 3D
brick-hole-cover.stl
STL Model
507.3 KB
File size
View 3D
brick-lamp.stl
STL Model
4.4 MB
File size
View 3D
brick-pavement.stl
STL Model
2.5 MB
File size
View 3D
brick-planter.stl
STL Model
5.2 MB
File size
View 3D
brick-planter-top.stl
STL Model
578.7 KB
File size
View 3D
brick-posts.stl
STL Model
4.1 MB
File size
Free download - login required
Downloaded: 58 times
